Avdragsapparater till mätning av slitlagrets bindeförmåga i betongkonstruktioner. Används till bestämning av ytstyrkan i betong och andra material. Kan därutöver användas till mätning av styrkan i beläggningar såsom plast, betongöverdrag, murbruk och puts etc. Kan användas till test av en punkt i en given struktur utan speciella anordningar innan för gjutning.
Används enligt standarder EN 1542, EN 1348, EN 1015-12, EN 13687-2, NF P18-858 / BS 1881:207 / ISO 4624, EN 13963 och 14496.
Compact, light and suitable for use in any location, this Pull-Off Tester is fitted with a load cell and high resolution large digital display unit; it is therefore suitable for measurements from low loads up to 16 kN, granting a wide working range and ideal for a large number of applications and materials. The direct tensile force is applied by rotating the hand wheel.
The three feet of the unit can be fixed in the large position (overall dimensions 176 mm diameter) with very stable bearing, or in the compact position (overall dimensions 92.5mm diameter), to perform tests in narrow spaces, or for specimens close one to the other.
Load capacity: 16 kN
Resolution: 10 N
Working range: 0.25 to 16 kN
Accuracy and repeatability: better than +/- 1%
Complete with traceable calibration certificate
Battery operated
Serial port for PC connection
Hand wheel rounds: 60 with mechanical round/counter
Graphic indication of the applied load rate
Seat ball assuring axial/central load application
Supplied complete with carrying case, but without accessories to perform the test, which have to be ordered separately.
To perform the test a common electric drill is required.
Dimensions: 410x210x270 mm
Weight: 5.5 kg approx.
